DESCRIPTION

Overview

Basic Info.

Layer Type	Common Laminated Glass
Function	Electromagnetic Shielding
Melting Point	High Temperature
Production	Dry Laminated Glass
Color	Clear
Usage	Furniture, Door, Building, Window
Technique	Clear Glass, Laminated Glass, Tempered Glass
Material	Pdlc
After-Sale Service	Online Technical Support, Onsite Installation, on
Application	Home Office, Hotel, Villa, Apartment, Office Build
Transport Package	Wooden Crates with Paper Interlayer
Specification	Customized Sizes From 300x300mm
Trademark	Tsing Glass
Origin	China
HS Code	39199010
Production Capacity	10000sqm/Day

Product Description

Smart Controllable Switchable/Anti-UV Self Adhesive Gray Smart Pdlc Film Use for Car Window Laminated Glass Electric Intelligent Glass Product Description

Smart PDLC film , also known as atomized film, electronic smart film, switchable film, electric curtain, PDLC switchable film is a kind of intelligent film, high-end functionality through voltage control dimming film implements double requirements of privacy, using this feature, dimming smart film is widely used in high-grade office, computer room, medical institutions, commercial display, etc.

Smart PDLC film adopts the technical principle of international invention patent, adheres the new liquid crystal material to the glass, film and other basic materials, and uses the circuit and control technology to make dimming glass products.What is the difference between Self Adhesive Smart Film and the Non Adhesive Smart Film.Smart Film Glass offers a Self Adhesive and a Non-Adhesive switchable privacy film that has the ability to contour to the curves of various types of glass. Smart Film is very popular for projection screens, electronic blinds, white boards, and high tech window treatments. smart PDLC film switchable privacy Glass provides maximum clarity when energized and extreme privacy when powered off. The only difference between the two switchable films is that Self Adhesive has a peel and stick backing and or non-adhesive can be installed with a double sided adhesive clear. Advantages1) Self-adhesive (Peel and stick)2) Can be applied onto the regular glass without replacing the existing glass3) UV / solar protection4) Removable5) Power: 65 V/AC (5 watts per square meter)6) Maximum cut size: 1.5m x 3.6mProduct Parameters

	Thickness:390±10 um
	Voltage: 60V
	Power: <10W/M2
	Parallel luminous transmittance(electricity off):<6
	Parallel luminous transmittance(electricity on):<65
	stickness: 200
	Voltage Tolerance: no breaking point,
Optics	Visible transmittance	Electricity On:>75%
		Electricity Off<1%
	Haze	Electricity On:<7%
		Electricity Off>90%
	viewing angle	Electricity On:about 140degree
	UV shielding	Electricity On:>99%
		Electricity Off>99%
	Shielding infrared	Electricity On:>30%
		Electricity Off>90%
Elecrical	Operation Voltage	Electricity on: 40V/48V/65VAC
	Response Time (in room)	Electricity Off-On: <200ms
		Electricity On-Off: >10ms
	Power	Electricity On: 6W/M2
Physics	Size	Thickness:0.55mm
		Max size: 1800*3500mm
Ambient		Operation Temp(On-Off):-30˚C-80˚C
		Storage Temp(On-Off):-40˚C-90˚C
Life		More than 10years
Sound		STC 6+6 Tempered Glass: 39dB
Switch Times		>3000 times

Application

1.Executive offices and conference room2.Control room of government facilities3.Family household and apartments4.Storefronts & Windows5.Transportation6.Privacy / security glass7.Glass walls doors8.Partitions/ Vision panels 9.Automobile window10.Presentation display Furniture ,Room partition

Technical Specifications of PDLC Film Self adhesive PDLC smart film is manufactured with a self-adhesive cling layer on rear side, you can peel and stick to the existing glass, which provides a simple and cost effective alternative to smart glass panel.Detailed Photos
Certifications

Packaging & Shipping

FAQ:

1.Can you project on Tsing Glass Smart Tint Film?

Yes,Tsing Glass smart tint is ideal for use as a projection film ,also the smart glass

2.Does it block the UV harmful rays?

Yes, it blocks 98% of the harmful UV rays in both its power on and off state

3.Is smart Tint energy efficient?

Yes, it is considered a green product that consumes between 3 and 5 watts per square meter

4.Is it less expensive than smart glass

Yes,it is a fraction of the cost and no construction required

5.Can smart film be installed on the top half of the glass only?

Yes,you can install the self-adhesive film on the top half or bottom only if desired

6.Can we install this smart film ourselves ?

Yes, that's the meaning of creation of self-adhesive smart film ,we will send you a install instruction if need.
